用 途Application
適合各種速食、速凍食品、肉類食品、果蔬堅果、茶葉、種子以及各種需要抗氧保鮮食品的真空包裝。
Suitable for all kinds of instant food ,frozen food ,meat ,fruits &
nuts ,tea leaves ,seeds and other anti-oxidized fresh food with vacuum packages
.
功 能Function
自動完成上料、提升輸送、電子稱重、制袋、充填、抽真空或充入氣體（需另配裝置）、封合、分切及成品輸送等作業。
Equipped with Z-type feeding ,multi-head electronic scale for weighting and
PLC control system that can auto materials-feeding ,lifting & conveying
,electronic weighting ,bag-making ,filling , vacuum-making or air-charging (need
extra vacuum device) ,sealing ,slitting and end out-feeding .
制袋類型Bag Style
枕式袋或立式袋，可配打孔裝置。
Pillow Bag or Vertical Bag (perforating device optional).
技術參數Technical Parameter
|
型號Type |
OMW-420 |
|
袋子尺寸Pouch Size |
Length 60-300mm ；Width 60-200mm |
|
包裝速度Capacity |
30-60ppm |
|
填充范圍Filling Range |
5-1500g |
|
包裝膜*大寬度Film Max. Width |
420mm |
|
包裝膜厚度Film Thickness |
0.04-0.09mm |
|
空氣消耗Air Consumption |
0.5m3/min |
|
功率Power |
2.2kw |
|
電源Voltage |
380V/50-60Hz |
|
機重Weight |
450kg |
|
外形尺寸Dimension |
1500x950x1400mm |
